Xhorse VVDI BIMTool Pro Enhanced Edition for BMW (New Version V1.8.0)

Xhorse VVDI BIMTool Pro Enhanced Edition for BMW (New Version V1.8.0)

Features:

• Ethernet port; supports 10/100M programming via Ethernet.
• Supports WI-FI 802.1b/g, 150Mbps high-speed connection, and WIFI OTA upgrade.
• Supports DoIP Vehicle/Module Programming.
• Supports BMW ECU programming (NBT/CIC) (connection via a network cable).
• Faster speeds for the F/G Chassis programming (connection via a network cable)
• Supports BMW E-sys and Rheingold Diagnostic System. Able to replace specialized devices. (connection via a network cable)
• Supports direct reading of ISN data without disassembling the ECU (N13/N20/N55/N63)

Functions of VVDI BIM Tool

E-Series programming, coding, DTCs

• Support autodetect car chassis
• Support scan all car units
• Support calculate all configuration units
• Support read/write car configuration(FA)
• Support input HW/ZB number to programming
• Support calculate default coding from FA
• Support edit detail coding information, change car config
• Support many languages DTC code

F-Series programming, coding, DTCs

• Support autodetect car chassis
• Support read/write car configuration(FA)
• Support calculate programming files from unit, car, whole database
• Support calculate default coding from FA
• Support edit detail coding information, change car config
• Support detail special function list from coding
• Support many languages DTC code

CAS1/CAS2/CAS3/CAS3+/CAS3++ISTAP OBD key learning

• Support read key information, write key information
• Support key learning
• Support read/write EEPROM
• Support read ECU/gearbox synchronize codes
• Support write ECU/gearbox synchronize codes
• Support synchronize ECU and CAS
• Support synchronize CAS and ELV
• Support read ISN via OBDII
• Support reset KM via OBDII
• Support disable key/enable key

CAS4(1L15Y)/CAS4+(5M48H) OBD key learning

• Support read CAS encrypt key via OBDII
• Support key learning via programmer and via ignition switch
• Support disable key/enable key
• Support erase key position
• Support reset KM via OBDII
• Support read ISN via OBDII
• Support backup/restore coding
• Support update original CAS4 file

FEM/BDC OBD key learning

• Support read FEM/BDC encrypt key via OBDII
• Support key learning via programmer and via ignition switch
• Support disable key/enable key
• Support erase key position
• Support reset KM via OBDII
• Support read ISN via OBDII
• Support backup/restore coding
• Support exchange used FEM/BDC
• Support close/open transport mode
• Support reset ECU lock
• Support switch on ignition without working key

CAS EEPROM dump key learning

• Support EWS1, EWS2, EWS3, EWS4, CAS1(0K50E), CAS2(2K79X), CAS3(0L01Y), CAS3+(0L15Y), CAS3++ISTAP(0L15Y, 0M23S)
• Support prepare dealer key via programmer
• Support disable key/enable key
• Support read ISN from working key

8HP Gearbox renew

• Support clear ISN in 8HP gearbox
• Support backup/restore coding
• Support reset adaptation information

Read synchronize code from E-Series ECU: Support MEV9N46L, MSV70, MSS60, MS450, N62, etc.

Read E-Series/F-Series ECU ISN via OBDII

• Support MSV80, MSV801, MSD80, MSD81, MSD802, MSD812, MSD851
• Support MED17xx/MVD17xx/MEVD17xx/MV1722
• Support MED172/MEV17N46/ME17N45
• Support MEVD172Y/MEVD172/MEVD1725/B38/X63TU

Support exchange ECU and CAS

• Support write ECU ISN via OBDII
• Support write ECU VIN via OBDII
• Support change ECU ISN and VIN with EEPROM dump
• Support change CAS1/CAS2/CAS3/CAS4 ISN and VIN with EEPROM dump

CAS repair(OBD&EEPROM)

• Support repair ISTAP CAS
• Support repair CAS EEPROM(Service mode EEPROM), you can start engine after repair the file(CAS1,CAS2,CAS3,CAS3+,CAS3++ISTAP)

CAS3+/CAS4+ lost all dump file support restore ISN and VIN

• Support CAS3+(1L15Y) encrypt version
• Support CAS3++(ISTAP) version
• Support CAS4+(5M48H) version

File KM calibration

• Support EWS1, EWS2, EWS3, EWS4
• Support CAS1(0K50E), CAS2(2K79X), CAS3(0L01Y), CAS3+(0L15Y, 0M23S)
• Support CAS4(1L15Y), CAS4(5M48H, 1N35H)
• Support E-Series dashboard EEPROM(M35080)
• Support F-Series dashboard EEPROM(35160, 35128)

Unlock HITAG2 key: Support lock hitag2 key made from BMW TOOL via programmer

EWS3/EWS4 can read EEPROM, write EEPROM via CAS PLUG
