TownSteel | SKU: TS-ED9700-36-32D

TownSteel - ED9700 - Rim Exit Device Push Bar - 36 - Satin Stainless - Grade 1 - ED9700-36-630

Name: TownSteel - ED9700 - Rim Exit Device Push Bar - 36 - Satin Stainless - Grade 1 - ED9700-36-630
Brand: TownSteel
SKU: TS-ED9700-36-32D
Price: 369.13 USD
Availability: InStock

$369¹³ ~~$442⁹⁶~~

Shipping calculated at checkout.

Secure transaction

Pickup available at MIAMI MAIN WAREHOUSE

Usually ready in 1 hour

Found a better price? Call for Price Match!
Shop with confidence knowing you’re getting the best deal.

Delivery and Shipping

All orders are shipped between 24 hours or less Monday through Friday from 9:00 am to 6:00pm. Orders placed after 5 p.m. EST will be shipped next business day.
Learn more

Return Policy

At Locksmith Keyless, we prioritize your satisfaction and offer a simple return process. Returns are accepted within 30 days of purchase for unused items in original packaging. Certain items, including OEM keys, Lishi tools, and customized orders, are non-returnable. A restocking fee of up to 30% may apply. For a full list of non-returnable items and more details, please refer to our complete return policy.

For damaged, missing, or incorrect items, please contact us within 48 hours of delivery. All returns require an RMA number. Shipping costs for returns are the responsibility of the customer.

View Full Return Policy

Description

TownSteel - ED9700 - Rim Exit Device Push Bar - 36" - Satin Stainless - Grade 1

Features

- Full line of exit devices are certified to ANSI/BHMA A156.3 Grade1.
- All devices are non-handed or reversible design.
- UL Listed for Fire Exit hardware, 3 hours.
- High shock-resistant latching mechanical design for vandalism protection.
- "A" Label (3 hr) rating on pairs of doors up to 8' x 8' for same or double egress.
- All internal components are made of electro -plated corrosion -resistant alloy.

Dimensions

Standard for Door Width 36"

Specifications

Handing

Non-handed

Finishes

630 standard (Consult factory for others)

Strikes

900 Rigid Strike standard

Alarm

Available with AK9

Latch bolt

Stainless Steel, 3/4" (19mm) throw

Dead Latch bolt

Stainless Steel

Dogging Feature

1/2 turn hex dogging standard

For non-fire rated devices

Cylinder Dogging

Available with CD9

Door Size

36" (914mm) standard, 48" (1219mm) available (Consult factory for others)

Minimum Stile Width

4 3/4" (120mm)

Door Thickness

1 3/4" - 2" (45-50.Bmm) standard (Consult factory for others)

Projection

Push bar Neutral 3 9/32" (83mm)

Push bar Depressed 2 17/32" (64.5mm)

Mounting Height

41" (104.1cm) from CL to finished floor

ANSI

Certified ANSI/BHMA A156.3 Grade 1 standard

Certified UL 305 & UL1QC fire rated, 3 hours

Shim Kit

950 Shim kit standard
