Sargent | SKU: SAR-28-10G71-24V-LL-BSP

Sargent - 28-10G71 - Electrified Cylindrical Lock Fail Secure with 2-3/4 Inch Backset and 4-7/8 Inch ANSI Strike - LA Keyway - 24V - LL Design - Optional Color

$723⁴⁸ ~~$839²³~~

Shipping calculated at checkout.

Color: BSP (Black Suede Powder Coat)

Sargent - 28-10G71 - Electrified Cylindrical Lock Fail Secure with 2-3/4 Inch Backset and 4-7/8 Inch ANSI Strike - LA Keyway - 24V - LL Design - Optional Color

Product variants

Secure transaction

Found a better price? Call for Price Match!
Shop with confidence knowing you’re getting the best deal.

Delivery and Shipping

All orders are shipped between 24 hours or less Monday through Friday from 9:00 am to 6:00pm. Orders placed after 5 p.m. EST will be shipped next business day.
Learn more

Return Policy

At Locksmith Keyless, we prioritize your satisfaction and offer a simple return process. Returns are accepted within 30 days of purchase for unused items in original packaging. Certain items, including OEM keys, Lishi tools, and customized orders, are non-returnable. A restocking fee of up to 30% may apply. For a full list of non-returnable items and more details, please refer to our complete return policy.

For damaged, missing, or incorrect items, please contact us within 48 hours of delivery. All returns require an RMA number. Shipping costs for returns are the responsibility of the customer.

View Full Return Policy

Description

Sargent - 28-10G71 - Electrified Cylindrical Lock Fail Secure with 2-3/4" Backset and 4-7/8" ANSI Strike - LA Keyway - 24V - LL Design - Optional Color

The 10 Line is the standard for institutional applications.

A heavy duty electrified cylindrical key-in-lever handle lockset exceeds by nine times the Grade 1 standards. As for abusive force, this lock endures more than 1.5 times the standard without allowing entry. The 10 line trim is designed to conform to national and state fire and handicapped requirements.

Feature:

10G70: Power off, unlocks outside lever
10G71: Power off, locks outside lever
Deadlocking latch
Key retracts latch
Inside lever always allows egress
Voltage requirements: 12VDC or 24VDC Regulated; always specify voltage
250mA at 24VDC or 500mA at 12VDC
Provided with ElectroLynx 8-Pin Connector

Product Specifications:

Vendor	Assa Abloy
Manufacturer	Sargent
SKU	28-10G71-24V LL BSP 28-10G71-24V LL 26D 28-10G71-24V LL 10B
UID	SAR2810G7124VLLBSP SAR1002810G7124VLL26D SAR1002810G7124VLL10B
Grade	Grade 1
Installation	Commercial
Origin	USA
Unit of Measure	Each
BAA Qualified	Yes
Fire Rated	3 Hours {A}
Finish	BSP US26D US10B

Technical Specifications:

Function	71-Electromechanical Fail Secure
Lever/Knob Design	L - Lever
Rose/Escutcheon Design	L - Rose
Cylinder Type	Conventional Cylinder
Num Pins	6
Keyway	LA
Keying	Keyed Different
Key(s)	Included
Number of Keys	2
Hand	Non Handed
Door Thickness	1-3/4" to 2"
Latch Number	472169
Latch Type	Dead Latch (Guarded)
Latch Backset Dim	2-3/4"
Lock Face Size	2-1/4" X 1-1/8"
Bolt Projection	1/2"
Strike Number	808
Strike Type	ASA
Strike Height	4-7/8"
Strike Width	1-1/4"
Screws	Combination
Power	Hard Wired
Operating Voltage	24VDC
Amp Draw	250mA
Product Type	Electric Cylindrical Lock
