BEA - Focus Family - Focused and Active Infrared Presence Sensors - 24V AC/DC
BEA's FOCUS Infrared Sensor (10FOCUS) is available to order from North Shore Commercial Door. The 10FOCUS is an overhead mounted infrared-based presence sensor that utilizes Distance Measuring technology. The compact FOCUS ensures safety in a number of applications where space may be limited or additional detection is needed to complement pre-installed sensors, such as on revolving doors where pinch-zone protection is needed. 10FOCUS is also idea for revolving doors, drive-up windows, sliding door side lite protection and industrial applications such as for machine guarding or gate and barrier access control.
Features:
- Focused Active Infrared presence sensor.
- Overhead mounted design.
- Effectively detect people and objects.
- Compact sensors can be used in situations where space may be limited or additional detection is needed to complement pre-installed sensors (such as revolving doors where pinch-zone protection is needed).
- Ideal for drive-thru/pass-thru applications.
- Can be used in gate and barrier applications.
- Fully adjustable sensors with relay outputs.
Specifications:
| Technology | Focused, active infrared |
| Detection Mode | Presence |
| Power Supply | 24 VAC/VDC ±10% |
| Current Consumption | 60 mA (on); 30 mA (off) |
| Output Interface; Relay | Relay; max. contact rating is 1 A at 30 V (resistive) |
| Detection Range | 0 – 8 1⁄5’ |
| Distance Adjustment | 2 – 8’, rotating cam with linear adjustment |
| Detection Time | < 50ms |
| Detection Signal Duration | Infinite presence detection |
| LED Activity | Green No detection |
| Operating Temperature | -30 – 140 °F |
| Connection to controller | 5-conductor cable |
| Relay Output | NO or NC |
